Descriptions
O-Rings are used in static sealing and some dynamic applications. O-Rings are made from materials that are matched to the fluids, temperatures and pressures found in engines and machines. The materials resist wear and extrusion, and provide superior resistance to seal compression set. In addition, certain O-Rings are coated with PTFE to minimize seal twisting and cutting during seal installation.
Attributes:
- Cross Section Diameter (in): 0.139
- Inside Diameter (in): 1.734
- SAE AS568 Dash Size: -224
- Material: FKM (75),FKM - Fluoroelastomer,FKM,Fluoroelastomer (FKM) Rubber
- Material Description: FKM rubber is capable of service temperatures of -40 to 150C and is resistant to air, fuel (including bio-diesel), lubricants and oils. FKM rubber should not be used in applications that require resistance to water or coolant.
- Notes: Dimensions and material descriptions provided for reference only.
- Polymer: FKM (Fluorocarbon)
- Applications: High temperature applications requiring resistance to air, fuels, lubricants and hydraulic fluids
- Not Compatible With: Amines; Brake fluids; Engine Coolant; Fire Resistant Fluids; Ketones; Steam; Water
- Material Hardness: 75A
- Compatible With: Diester lubricants; Halogenated hydrocarbons (above 100 Deg. C); Highly resistant to compression set; Petroleum fluids; Phosphate ester fluids; Silicone fluids; Some acids
- Dash Size: 224
- Temperature (°F): -40 - 350
- Seal/O-Ring Type: Standard
Compatible Models
PUMPER
SPS342 CPT372 SPT342 SCT673
UNDERGROUND ART TRUCK
AD55 AD30
GENERATOR
SR4 SR4B
TRUCK ENGINE
C-10 C-12 3406C 3406B C-15 3176 3176B C15
POWER MODULE
PM3456
INTEGRATED TOOLCARRIER
IT18B IT28B
LOAD HAUL DUMP
R1700 II R2900G R1600 R1700G R2900
REMAN ENGINE
3406E
OFF HIGHWAY TRUCK
796 AC 798
MOTOR GRADER
18
WINCH
528
WHEEL SKIDDER
518 528 518C
TRACK-TYPE TRACTOR
D7G D6 D4E D4E SR D6T
MARINE ENGINE
C12 C15 3412 3406B
STABILIZER MIXER
SM-350
WHEEL TRACTOR
613 631E 631C 637E
GENERATOR SET
G3516B G3520B
RECLAIMER MIXER
RM-350
HYDRAULIC CONTROL
173B
TRACK LOADER
973 943 953
COLD PLANER
PR-1000C PR-1000
WHEEL LOADER
980 XE 960F 972H 950B/950E 950B 950E 950F G926 916 936E 924G G916 926 980H 936 926E G936 966H 994K 982 XE 950F II
ROAD RECLAIMER
RR-250
SOIL STABILIZER
SS-250
CHALLENGER
75C 85C
ENGINE - MACHINE
C4.4 3176C 3208
GEN SET ENGINE
3406C 3406B 3412 G3412C 3412C G3516B G3520B 3508
ENGINE - INDUSTRIAL
3406B 3406C
INDUSTRIAL ENGINE
3412 3406C C15
WHEEL SCRAPER
623F 623E 657 657B
TRUCK
793F CMD 797 793F OEM 775D 795F XQ 793D 793F 795F AC 777C 777B MT4400D AC 793F XQ 773D 797F 777 794 AC 769D 769C 785C 785D 797B 773B
QUARRY TRUCK
771D 771C 775B
TRACTOR
776 776C 776B 772B 768C
GAS ENGINE
G3612 G3608
BULLDOZER
8A 824S 8S
