Descriptions
O-Rings are used in static sealing and some dynamic applications. O-Rings are made from materials that are matched to the fluids, temperatures and pressures found in engines and machines. The materials resist wear and extrusion, and provide superior resistance to seal compression set. In addition, certain O-Rings are coated with PTFE to minimize seal twisting and cutting during seal installation.
Attributes:
- Cross Section Diameter (in): 0.103
- Inside Diameter (in): 0.424
- SAE AS568 Dash Size: -111
- Material: FKM (75),FKM - Fluoroelastomer,FKM,Fluoroelastomer (FKM) Rubber
- Material Description: FKM rubber is capable of service temperatures of -40 to 150C and is resistant to air, fuel (including bio-diesel), lubricants and oils. FKM rubber should not be used in applications that require resistance to water or coolant.
- Notes: Dimensions and material descriptions provided for reference only.
- Polymer: FKM (Fluorocarbon)
- Applications: High temperature applications requiring resistance to air, fuels, lubricants and hydraulic fluids
- Not Compatible With: Amines; Brake fluids; Engine Coolant; Fire Resistant Fluids; Ketones; Steam; Water
- Material Hardness: 75A
- Compatible With: Diester lubricants; Halogenated hydrocarbons (above 100 Deg. C); Highly resistant to compression set; Petroleum fluids; Phosphate ester fluids; Silicone fluids; Some acids
- Dash Size: 111
- Temperature (°F): -40 - 350
- Seal/O-Ring Type: Standard
Compatible Models
PUMPER
CPT372
TRUCK ENGINE
C-10 3406E C-15 3176 3176B C11 C15 C18
POWER MODULE
PM3456
INTEGRATED TOOLCARRIER
IT12B IT28F
LOAD HAUL DUMP
R1700 II R1600 R1700G R2900
MOTOR GRADER
12M 3 140M 3 AWD 12M 3 AWD 140M 3 160M 3 160M 3 AWD
BACKHOE
931 D3
TRACK-TYPE TRACTOR
D6GC D8L D3B D4B
MARINE ENGINE
C18 C12 C15 D330B D330C 3508B 3512B 3304 3304B 3406E 3516B
MARINE AUXILIARY
3516B 3512B 3508B
PIPELAYER
589
EXCAVATOR
323F SA M312 M315 M318 M320
GENERATOR SET
C32
WHEEL TRACTOR
631E 637E
MARINE TRANSMISSION
7241 7261
HYDRAULIC CONTROL
48
TRACK LOADER
963 973 935B
PETROLEUM ENGINE
C32
BACKHOE LOADER
414E 446B 416E
COLD PLANER
PM-565
COMPACT WHEEL LOADER
910F 910E
WHEEL LOADER
980 XE 972H 972M 980H 928F 966H 966M 982 XE
CHALLENGER
75C 85C
ENGINE - MACHINE
C4.4 3176C
GEN SET ENGINE
3406E 3608 3606 3516B 3456 3616 3512B 3508B
TRANSMISSION
CX31
MARINE GEAR
3192 7251
SKID STEER LOADER
216 226
INDUSTRIAL ENGINE
D320A 3406E 3456 C13 C15
WHEEL SCRAPER
657 657B
TRUCK
793F CMD 797 793F OEM 775D 793F MT4400D AC 793F XQ 773D 794 AC 769D 769C 773B
QUARRY TRUCK
771D 771C 775B
GAS ENGINE
G3612 G3616 G3606
BULLDOZER
8A 8S 3S 3P
