Descriptions
O-Rings are used in static sealing and some dynamic applications. O-Rings are made from materials that are matched to the fluids, temperatures and pressures found in engines and machines. The materials resist wear and extrusion, and provide superior resistance to seal compression set.
O-Rings are coated with PTFE to minimize seal twisting and cutting during seal installation. Dimensions of our O-Rings are consistently held to tight tolerances to ensure they fit properly into seal grooves with the necessary seal compression.
Attributes:
- Cross Section Diameter (in): 0.21
- Inside Diameter (in): 0.912
- SAE AS568 Dash Size: -317
- Material: VMQ - Silicone,Silicone (70),Silicone (VMQ),Silicone / MQ / VMQ / PMQ Rubber
- Material Description: Silicone (VMQ) rubber is capable of service temperatures of -55 to 150C and is resistant air. Silicone rubber should not be used in applications that require resistance to fuel, oil and coolants.
- Notes: Dimensions and material descriptions provided for reference only.
- Polymer: VMQ (Silicone rubber)
- Applications: Electrical system seals; High temperature air seals; High temperature static grease seals
- Not Compatible With: Acetone; Aromatic hydrocarbons; EP oil; Fuel oil; Gasoline; Ketones; Low aniline point oils; Petroleum oils; Steam & hot water
- Material Hardness: 70A
- Compatible With: Air; Diacetone alcohol; Ethylene glycol; Extreme high/low temperatures; High aniline point oil; Iso-butyl alcohol; Ozone & UV light; Polyglycol
- Dash Size: 317
- Temperature (°F): -50 - 300
- Seal/O-Ring Type: Standard
Compatible Models
GENERATOR
SR4 SR4B
TRUCK ENGINE
C7 3408B 3126B 3408 3406 3126E 3306 1673C 3406E 3406C 3406B 3116 G3306 3306C 3306B
INTEGRATED TOOLCARRIER
IT12B IT28G IT28F
LOAD HAUL DUMP
R1300
MOTOR GRADER
120H 120G 120B 140B 140G 130G 140 14E 120 160G 12F
WINCH
528 55
TRACK-TYPE TRACTOR
D10 D4D D4E D5B D5H D6C D6D D7G2 D6E D6H D7F D7G D5 D8K D8L D6G2 XL D4E SR
WHEEL SKIDDER
525 518 528
MARINE AUXILIARY
3516B
MARINE ENGINE
3516 3512 3508 D330C 3408B D333C 3304 3306 3304B 3412 3408 3406
PIPELAYER
561D 561C 572F 571F 589
EXCAVATOR
320-A L 320-A N 350-A L 350 L 225 235 320-A 215 320N 375-A 245 245B M318 320 L
VIBRATORY COMPACTOR
CS-563 CP-563 CB-434
WHEEL TRACTOR
651B 627 631E 641B 657B 621E 627B 637E
HYDRAULIC CONTROL
48 163 143 183B 153 141 140
TRACK LOADER
973 941 951C 951B 953C 941B 977K 955K 955L
SOIL COMPACTOR
825C 815
BACKHOE LOADER
446B
COLD PLANER
PR-450
WHEEL DOZER
824C 814
LANDFILL COMPACTOR
816
COMPACT WHEEL LOADER
910F 910E
WHEEL LOADER
928G 972G 960F 950G 962G 950F 920 988B 930 936 966D 966C 966E 966G 950 930R 930T 966F II 936E 924G 980B 980C 980F 928F 938G 938F 970F 950F II
TELEHANDLER
RT80 RT100
ENGINE - MACHINE
3116 3304 3306 3406B
CHALLENGER
55 70C 35 45
GEN SET ENGINE
3406B 3408B 3408C 3516B 3304B 3116 3306 3304 G3516B 3508 3408 3512 3516
ARTICULATED TRUCK
D250B D300E II
RIPPER
8D 977 951 955 10 6 5 4
ENGINE - INDUSTRIAL
3406B
INDUSTRIAL ENGINE
3406C 3126 3306B 3304 3306 D320A 3412 D333C 3304B 3406 3512 3516 3508 D330C
TRUCK
773B 773 769C
WHEEL FELLER BUNCHER
533
WHEEL SCRAPER
627 621E 623F 623E 613C 639D 627B 615C 637 TRACTOR 768C 772B
GAS ENGINE
G333C G3306 G343 G3516
BULLDOZER
7SU 7S LGP 824S 8S 4S 10C 5A 5S 6A 6S 10S 7S 10U 8A 4A
TRACK-TYPE LOADER
977K
