Descriptions
O-Rings are used in static sealing and some dynamic applications. O-Rings are made from materials that are matched to the fluids, temperatures and pressures found in engines and machines. The materials resist wear and extrusion, and provide superior resistance to seal compression set. In addition, certain O-Rings are coated with PTFE to minimize seal twisting and cutting during seal installation.
Attributes:
- SAE AS568 Dash Size: N/A
- Material: FKM - Fluoroelastomer,FKM (90),FKM,Fluoroelastomer (FKM) Rubber,Polytetrafluoroethylene (PTFE) Plastic
- Cross Section Diameter (in): 0.055
- Inside Diameter (in): 1.009
- Material Description: FKM rubber is capable of service temperatures of -40 to 150C and is resistant to air, fuel (including bio-diesel), lubricants and oils. FKM rubber should not be used in applications that require resistance to water or coolant.
- Notes: Dimensions and material descriptions provided for reference only.
- Polymer: FKM (Fluorocarbon)
- Applications: High pressure, high temperature applications requiring resistance to air, fuels, lubricants and hydraulic fluids; ORFS, STORS seals
- Not Compatible With: Amines; Brake fluids; Engine Coolant; Fire Resistant Fluids; Ketones; Steam; Water
- Material Hardness: 90A
- Compatible With: Diester lubricants; Halogenated hydrocarbons (above 100 Deg. C); Highly resistant to compression set; Petroleum fluids; Phosphate ester fluids; Silicone fluids; Some acids
- Temperature (°F): -40 - 350
- Seal/O-Ring Type: Standard
- Primary Sealing Material: Rubber
Compatible Models
UNDERGROUND ART TRUCK
AD55 AD30
GENERATOR SET
C32
WHEEL TRACTOR
637E 631E
TRUCK ENGINE
3406E C-15 C-16 C13 C15
POWER MODULE
PM3456
MARINE ENGINE
3406E
INDUSTRIAL ENGINE
C13 C15 3456
WHEEL SCRAPER
657 657B
LOAD HAUL DUMP
R2900G R2900
MOTOR GRADER
18
COMBAT VEHICLE ENGINE
C13
WHEEL LOADER
980 XE 966H 972H 980H 982 XE
